Cover & Table of Contents

Cover

⤢ zoomOperator's manual cover: a black-and-white photograph of the X-150D on a wooden sideboard above a stereo amplifier, set against a brown ground, with the titling AKAI X-150D OPERATOR'S MANUAL and, below, CROSS-FIELD Custom Deck

The cover repeats the machine's own badging — AKAI X-150D, the CROSS-FIELD mark, and the Custom Deck script that also appears on the deck panel itself.

Table of Contents

Chapter	Section	Page
I	GENERAL INFORMATION	2
I.1	Specifications	2
I.2	Controls	3
I.3	Cross-Field Head	5
I.4	Recording/Playback for 4-track	6
I.5	Operational Precautions	7
I.6	Voltage and Cycle Conversion	8
I.7	Selection of Tape Speeds	9
II	OPERATING INSTRUCTIONS	10
II.1	Threading the Tape	10
II.2	Stereo Playback	10
II.3	Automatic Shut-Off	11
II.4	Instant Stop Control	11
II.5	Stereo Recording	12
II.6	Recording from Stereo Broadcast	13
II.7	Recording from Stereo Discs	13
II.8	Monaural Recording on Tracks No. 1-4	13
II.9	Monaural Recording on Tracks No. 3-2	14
II.10	Monaural Playback	15
II.11	Tape Erasing	15
II.12	Fast Forward and Rewind	16
II.13	Monitoring	16
II.14	Tape Splicing and Editing	16
II.15	Cleaning Head	17
II.16	Head Demagnetization	19
II.17	Tape Duplication	19
II.18	DIN (One Multiple Connection) Jack	20
II.19	Ventilation	20
III	ACCESSORIES	21
III.1	Accessories Optional	21
III.2	Accessories Standard	23
IV	SCHEMATIC	—
V	CONNECTING DIAGRAM	—
